Purpose:
Radar “Barsuk” is patrol portable radar provides detection of persons, surface land and sea vehicles.
Description:
112L1 “Barsuk” is patrol portable radar provides detection of persons, surface land and sea vehicles. It can be used to provide security of land and sea areas of state borders, for the protection of military, administrative and service buildings (warehouses, nuclear power plants, residences of important people, etc.) in all weather conditions in the absence of optical visibility. Information about moving target is displayed as signal amplitude (target identification - person, group of persons, vehicle, animal - is carried out via sound channel with headphones).
Technical details:
|
Frequency
|
36 GHz
|
|
Detection range:
|
|
|
- Person
|
1200 m.
|
|
- Vehicle
|
3000 m.
|
|
- Watercraft
|
1200 m.
|
|
Resolution:
|
|
|
- azimuth
|
3°
|
|
- range
|
25 m, 50 m
|
|
Transmitted power
|
0,075 W
|
|
Recognition mode
|
By operator with headphones
|
|
Representation
|
LCD display
|
|
Weight
|
5,5 kg.
|
|
Azimuth view sector
|
360°
|
|
Operating temperature
|
-30°…+50°С
|
|
Voltage
|
12 V
|
|
