Purpose:
Automated jamming complex
Description:
It is intended for suppression of ground-based communication
lines with fixed operating frequencies of any
modulation types and hopping frequencies in HF, VHF
and UHF bands by means of selective in frequency and
time barrage jamming. It is an automated system of
data gathering and processing about the radio emitting
sources. It is also used for radio jamming organization
in the covering area. It provides simultaneous effective
suppression of up to 80 communication lines with fixed
operating frequencies or up to 6 radio networks with frequency
hopping in controlled area of 60 km in depth and
90 km in front.
The complex consists of R-330 RD automated reconnaissance
station of HF, VHF and UHF bands, R-330 KV1
automated jamming station of HF band, R-330 UV1 automated
jamming station of VHF band and R-330 UV2
automated jamming station of UHF band.
|
